SolarEdge P405-4NM4MRM-NM25 405W Power Optimizer – MC4 – North America

The SolarEdge P405 Power Optimizer is a module-level DC power optimizer designed for use with compatible SolarEdge inverter systems. Rated for photovoltaic modules up to 405 watts, the P405 features a substantially higher input-voltage capability than many standard SolarEdge P-Series optimizers, making it particularly suitable for thin-film and other higher-voltage PV modules.

Installed at the individual solar module, the P405 performs module-level Maximum Power Point Tracking (MPPT), helping maximize energy production and reduce losses caused by shading, module mismatch, soiling, aging, and variations between individual solar panels.

Specifications:

• Manufacturer: SolarEdge
• Model: P405
• Part Number: P405-4NM4MRM-NM25
• Rated Input DC Power: 405W
• Absolute Maximum Input Voltage: 125V DC
• MPPT Operating Range: 12.5–105V DC
• Maximum Output Current: 15A DC
• Maximum Output Voltage: 85V DC
• Maximum Efficiency: 99.5%
• Weighted Efficiency: 98.8%
• Safety Output Voltage: Approximately 1V per optimizer
• Maximum System Voltage: 1000V DC
• Input Connection: MC4
• Module-Level MPPT
• Module-Level Monitoring capability
• SolarEdge SafeDC safety functionality
• Designed for compatible SolarEdge inverter systems
• North American configuration
